| P/N |
CA-1Z4-00M1WN-00
|
| Series |
View |
| Model |
View 170 TG ARGB |
| CASE TYPE |
Micro Case |
| Dimension (H x W x D) |
438 x 212 x 377.5 mm
(17.24 x 8.35 x 14.86 inch) |
| NET WEIGHT |
4.65 kg / 10.25 lbs. |
| PANEL |
3mm Tempered Glass x 2
|
| Color |
Black |
| MATERIAL |
SPCC
|
| COOLING SYSTEM |
Right(intake):
120 x 120 x 25 mm ARGB Lite fan (1000rpm, 22.3 dBA) x 2
Rear(exhaust):
120 x 120 x 25 mm ARGB Lite fan (1000rpm, 22.3 dBA) x 1
|
| Drive Bays |
1 x 3.5”, 2 x 2.5”
|
| EXPANSION SLOTS |
4 |
| MOTHERBOARDS |
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX) |
| I/O Port |
USB 3.0 x 2, HD Audio x 1 |
| PSU |
Standard PS2 PSU (optional) |
| FAN SUPPORT |
Top:
2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm
Right:
2 x 120mm, 1 x 120mmRear: 1 x 120mm
Power Cover:
2 x 120mm, 1 x 120mm |
| RADIATOR SUPPORT |
Top:
1 x 240mm, 1 x 120mm
1 x 280mm, 1 x 140mm
Rear:
1 x 120mm |
| CLEARANCE |
CPU cooler max height: 160mm
VGA max length: 340mm
PSU max length: 180mm |
