| P/N |
CA-1Y7-00M6WN-01 |
| Series |
View |
| CASE TYPE |
Mid Tower |
| Dimension (H x W x D) |
456 x 230 x 454 mm
(18 x 9.1 x 17.9 inch) |
| NET WEIGHT |
6.35 kg / 14 lbs. |
| PANEL |
Tempered Glass x 2 |
| Color |
White |
| MATERIAL |
SPCC |
| COOLING SYSTEM |
Right(intake):
120 x 120 x 25 mm ARGB Lite fan (1000rpm, 22.3 dBA) x 2
Rear(exhaust):
120 x 120 x 25 mm ARGB Lite fan (1000rpm, 22.3 dBA) x 1 |
Drive Bays
-Accessible
-Hidden |
2 x 3.5”, 1 x 2.5” or 2 x 2.5” |
| EXPANSION SLOTS |
7 |
| MOTHERBOARDS |
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX),
12” x 9.6” (ATX), 12” x 13” (E-ATX) |
| I/O Port |
USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1 |
| PSU |
Standard PS2 PSU (optional) |
| FAN SUPPORT |
Top:
3 x 120mm, 2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm
Right (M/B Side):
2 x 120mm, 1 x 120mm
Rear:
1 x 120mm, 1 x 140mm
Power Cover:
3 x 120mm, 2 x 120mm, 1 x 120mm |
| RADIATOR SUPPORT |
Top:
1 x 360mm, 1 x 240mm, 1 x 120mm
Rear:
1 x 120mm
|
| CLEARANCE |
CPU cooler max height: 180mm
VGA max length: 420mm
PSU max length: 220mm |
